Space Shuttle Gallery

Choose from 245 pictures in our Space Shuttle collection for your Wall Art or Photo Gift. All professionally made for Quick Shipping.


NASA Langley Magnetic Suspension/Balance System Featured Space Shuttle Print

NASA Langley Magnetic Suspension/Balance System

A shuttle model is magnetically suspended in the transparent hexagonal test section of the MIT/NASA Langley 6 inch MSBS. Massive power supplies are required to drive electromagnets for model position control. A unique electromagnetic position sensor, similar to a linear variable differential transformer, provides five degrees of freedom for the test model. The low speed (Mach 0.5) wind tunnel was hand crafted from mahogany. Aerodynamic forces on the test model are measured by the proportional electrical current used to hold the model in place. The system was built by MIT in the late sixties, and was relocated to Langley in the mid eighties. In a joint effort with Old Dominion University in 1992 the MSBS was used to test the aerodynamics of store separation, simulating a bomb released from an aircraft. The system has been donated to Old Dominion University

© NASA

Endeavour is Delivered to the Kennedy Space Center Featured Space Shuttle Print

Endeavour is Delivered to the Kennedy Space Center

NASA's 747 Shuttle Carrier Aircraft No. 911, with the space shuttle orbiter Endeavour securely mounted atop its fuselage, taxies to the runway to begin the ferry flight from Rockwell's Plant 42 at Palmdale, California, where the orbiter was built, to the Kennedy Space Center, Florida. At Kennedy, the space vehicle was processed and launched on orbital mission STS-49, which landed at NASA's Ames-Dryden Flight Research Facility (later redesignated Dryden Flight Research Center), Edwards, California, May 16 1992. NASA 911, the second modified 747 that went into service in November 1990, has special support struts atop the fuselage and internal strengthening to accommodate the added weight of the orbiters

© NASA

Northrop HL-10 lifting body aircraft Featured Space Shuttle Print

Northrop HL-10 lifting body aircraft

Northrop HL-10 lifting body aircraft. Major Jerauld Gentry standing in front of the HL-10. This was one of a series of experimental space re-entry aircraft known as lifting body designs. Lifting body aircraft had short, bulbous or curved fuselages and featured minimal wings or were wingless. The design increased the aerodynamic capabilities of the aircraft when travelling at speed and the absence of wings meant less heat damage during space re-entry. The HL-10 was built in 1966 and dropped from B-52 planes to test flight manoeuvrability. Despite its success, NASA cancelled the lifting body design in favour of the delta wing during early Space Shuttle development

© NASA/SCIENCE PHOTO LIBRARY
