Brunels tunnelling shield

The tunnelling shield, or excavating machine designed by Sir Marc Isambard Brunel (1769- 1849) & used in the construction of the lining of the Thames tunnel. The shield (right) consists of twelve frames, which could be edged forward independently, supporting the side of the tunnel while allowing bricklayers to work from it. A moveable stage enabled building materials to be brought up to the level of the advancing face of the lining. The tunnel, running under the Thames between Rotherhithe & Wapping, was begun by Sir Marc Brunel in 1825 & completed in 1873 after his death. It was designed for foot passengers & later taken over by London Underground

© SCIENCE PHOTO LIBRARY

Landore Viaduct construction, near Swansea, South Wales

View of construction work on the Landore Viaduct, over the Swansea valley and the River Tawe, on the Great Western Railway, Glamorgan, South Wales. The original timber viaduct was designed by Brunel, and completed in 1852. The new structure, completed in 1889, used wrought iron for the central span

© Mary Evans Picture Library 2015 - https://copyrighthub.org/s0/hub1/creation/maryevans/MaryEvansPictureID/10428942

1850s, 1852, 1880s, 1887, 1889, Brunel, Building, Central, Construction, Engineering, Girder, Girders, Glamorgan, Great, Gwr, Historical, History, Hut, Iron, Landore, Metal, New, Railway, River, South, Span, Structure, Swansea, Tawe, Timber, Valley, Viaduct, Victorian, Wales, Welsh, Western, Wood, Wooden, Work, Wrought

Brunels SS Great Eastern, Milford Haven, South Wales

Brunel's iron sailing steamship, the SS Great Eastern, berthed at Milford Haven, Pembrokeshire, South Wales, during the 1870s. The ship is so large that it runs the length of Hamilton Terrace. Around this time the ship was being used for the laying of submarine telegraph cables. She was eventually broken up in 1889-1890
